Horizontal Plate Lifting Clamp

The Toyolift PLC pipe lifting clamps provide a durable are used in sets of two for the horizontal transportation of pipe sections. Attachment and removal of the clamps from the pipe is extremely easy due to the simple and straightforward design. The working load limits shown on the technical parameter table are based on a set of two clamps used together. Pipe Hooks provide a fast and efficient method for lifting pipe, tube or any similarly shaped fabrications. Compact shape and relatively low unit weight with high lifting W.L.L. It can only be used in pairs using a two-leg sling or spreader beam.

<p>The Toyolift PLC pipe lifting clamps provide a durable are used in sets of two for the horizontal transportation of pipe sections. Attachment and removal of the clamps from the pipe is extremely easy due to the simple and straightforward design. The working load limits shown on the technical parameter table are based on a set of two clamps used together.</p><p>Pipe Hooks provide a fast and efficient method for lifting pipe, tube or any similarly shaped fabrications.  Compact shape and relatively low unit weight with high lifting  W.L.L. It can only be used in pairs using a two-leg sling or spreader beam. </p><div><br></div>

Download Product Datasheet

Product datasheet

• Details
• Parameters
• Drawings
• References

The Toyolift PLC pipe lifting clamps provide a durable are used in sets of two for the horizontal transportation of pipe sections. Attachment and removal of the clamps from the pipe is extremely easy due to the simple and straightforward design. The working load limits shown on the technical parameter table are based on a set of two clamps used together.

Pipe Hooks provide a fast and efficient method for lifting pipe, tube or any similarly shaped fabrications.  Compact shape and relatively low unit weight with high lifting  W.L.L. It can only be used in pairs using a two-leg sling or spreader beam.

HORIZONTAL PLATE LIFTING CLAMP
TYPE	Capacity per pair (Ton)	Jaw opening (mm)	Dimensions
			A	B	C	D	E
TL-FHX010	1	0-60	210	165	80	12	110
TL-FHX015	1.5	0-60	285	180	80	14	120
TL-FHX020	2	0-60	285	180	80	15	120
TL-FHX030	3	0-60	303	220	90	18	145
TL-FHX050	5	0-60	309	220	110	25	135
TL-FHX100	10	0-60	330	225	110	25	140

Standard: EN 13155
